Flat membrane for sewage treatment

MBR Membrane Products—Flat sheet Membrane

Products Introduction

• Flat sheetmembrane element consists of solidABS plate, antibacterial flow guide layer and inlaid PVDF flat membrane sheet. The use of the vertical state, the sewage filtered by the membrane at the same time the bottom of the aeration of the membrane surface flushing, so that the activated sludge is not easy to be deposited on the membrane surface, to extend the membrane cleaning cycle, to ensure that the membrane equipment long-term stability.




Product characteristics

• Hydrophilic skin layer, near-skin layer and porous support layer are spongy, dense and topological structure in order of gradual progression, with higher porosity.

• Strong capillary force reduces the membrane pore resistance and improves permeate flux in the application of the membrane.

• Separation layer and support layer form a semi-interpenetrating network, which improves interlayer adhesion and bursting strength, prolonging service life.

Product Advantages

• Better anti-pollution performance: It can maintain high flux at higher activated sludge concentration, with superior anti-pollution performance.

• Good mechanical stability: high strength support will not tear phenomenon, can completely ensure high quality water.

• More convenient cleaning method, longer cleaning cycle: Bottom aeration combined with large bubbles, effective shear on the surface of membrane, long chemicalcleaning cycle.

• Long life, low operating costs: life is normally 5-8 years, do not need to frequently replace the membrane sheet, unique design can be a single sheet replacement.

Product Specification

PSD80 series flat MBR membrane module Key Parameters

Key Parameters of PSD100 Series Flat Sheet MBR Membrane Module

Key Parameters of PSD150 Series Flat Sheet MBR Membrane Module

Fields of application

• Municipal wastewater reuse

• Integrated domestic wastewater equipment

• Black Odor Water Treatment

• Dyeing wastewater treatment

• Chemical wastewater treatment

• Food and beverage wastewater treatment
